바깥지름
D
|
두께
t
|
단면적
A
|
단위질량
W
|
참고
|
단면2차 모멘트
I
|
단면계수
Z
|
단면2차반지름
i
|
바깥쪽표면적
|
mm
|
mm
|
㎠
|
kg/m
|
cm⁴
|
cm³
|
㎝
|
㎡/m
|
400
|
9
12
|
110.6
146.3
|
86.8
115
|
211× 10²
276× 10²
|
105.7× 10
137.8× 10
|
13.8
13.7
|
1.26
1.26
|
406.4
|
9
12
|
112.4
148.7
|
88.2
117
|
222× 10²
289× 10²
|
109.2× 10
142.4× 10
|
14.1
14.0
|
1.28
1.28
|
500
|
9
12
14 |
138.8
184.0
213.8
|
109
144
168
|
418× 10²
548× 10²
632× 10²
|
167× 10
219× 10
253× 10
|
17.4
17.3
17.2
|
1.57
1.57
1.57
|
508.0
|
9
12
14
|
141.1
187.0
217.3
|
111
147
171
|
439× 10²
575× 10²
663× 10²
|
173× 10
227× 10
261× 10
|
17.6
17.5
17.5
|
1.60
1.60
1.60
|
600
|
9
12
14
16
|
167.1
221.7
257.7
293.6 |
131
174
202
230
|
730× 10²
958× 10²
111× 10³
125× 10³
|
243× 10
319× 10
369× 10
417× 10
|
20.9
20.8
20.7
20.7
|
1.88
1.88
1.88
1.88
|
609.6
|
9
12
14
16
|
169.8
225.3
262.0
298.4
|
133
177
206
234
|
766× 10²
101× 10³
116× 10³
132× 10³
|
251× 10
330× 10
381× 10
431× 10
|
21.2
21.1
21.1
21.0
|
1.92
1.92
1.92
1.92
|
700
|
9
12
14
16
|
195.4
259.4
301.7
343.8
|
153
204
237
270
|
117× 10³
154× 10³
178× 10³
201× 10³
|
333× 10
439× 10
507× 10
575× 10
|
24.4
24.3
24.3
24.2
|
2.20
2.20
2.20
2.20
|
711.2
|
9
12
14
16
|
198.5
263.6
306.6
349.4
|
156
207
241
274
|
122× 10³
161× 10³
186× 10³
211×10³
|
344× 10
453× 10
524× 10
594× 10
|
24.8
24.7
24.7
24.6
|
2.23
2.23
2.23
2.23
|
mm
|
mm
|
㎠
|
kg/m
|
m⁴
|
m³
|
㎝
|
㎡/m
|
800
|
9
12
14
16
|
223.6
297.1
345.7
394.1
|
176
233
271
309
|
175× 10³
231× 10³
267× 10³
303× 10³
|
437× 10
577× 10
668× 10
757× 10
|
28.0
27.9
27.8
27.7
|
2.51
2.51
2.51
2.51
|
812.8
|
9
12
14
16
|
227.3
301.9
351.3
400.5
|
178
237
276
314
|
184× 10³
242× 10³
280× 10³
318× 10³
|
452× 10
596× 10
690× 10
782× 10
|
28.4
28.3
28.2
28.2
|
2.55
2.55
2.55
2.55
|
900
|
12
14
16
19
|
334.8
389.7
444.3
525.9
|
263
306
349
413
|
330× 10³
382× 10³
434× 10³
510× 10³
|
733× 10
850× 10
965× 10
113× 10²
|
31.4
31.3
31.3
31.2
|
2.83
2.83
2.83
2.83
|
914.4
|
12
14
16
19
|
340.2
396.0
451.6
534.5
|
267
311
354
420
|
346× 10³
401× 10³
456× 10³
536× 10³
|
758× 10
878× 10
997× 10
117× 10²
|
31.9
31.8
31.8
31.7
|
2.87
2.87
2.87
2.87
|
1000
|
12
14
16
19
|
372.5
433.7
494.6
585.6
|
292
340
388
460
|
455× 10³
527× 10³
599× 10³
705× 10³
|
909× 10
105× 10²
120× 10²
141× 10²
|
34.9
34.9
34.8
34.7
|
3.14
3.14
3.14
3.14
|
1016.0
|
12
14
16
19
|
378.5
440.7
502.7
595.1
|
297
346
395
467
|
477× 10³
553× 10³
628× 10³
740× 10³
|
939× 10
109× 10²
124× 10²
146× 10²
|
35.5
35.4
35.4
35.3
|
3.19
3.19
3.19
3.19
|
1100
|
12
14
16
19
|
410.2
477.6
544.9
645.3
|
322
375
428
506
|
607× 10³
704× 10³
800× 10³
943× 10³
|
110× 10²
128× 10²
146× 10²
171× 10²
|
38.5
38.4
38.3
38.2
|
3.46
3.46
3.46
3.46
|
강관말뚝
